- Brand Name: FeiyuTech
- of Axes: 3-Axis
- Titling Angle: 230°
- Configured for: DSLRs
- Configured for: action photo cameras
- Configured for: mirrorless cameras
- Origin: CN(Origin)
- Communication: WIFI
- Communication: Wired
- Type: handheld gimbal
- Rolling Angle: 306°
- Certification: CE
- Panning Angle: 360°
- Model Number: AK2000C
- Package: Yes
- Feature: Following the shooting mode
- Support Remote Control: No
- App Setting: Yes
- Supported Mobile Device Max Size: 2.2Kg
- Material: Aluminum
- Charging for Mobile Device: Yes
- Camera Integration: No
- Weight (g): 1078g
- Size: 147.4*203.6*372.8mm
- Vertical Shooting: Yes
Feiyu AK2000C is another version of Feiyu AK2000S. Don't underestimate this gimbal just because the AK2000C is cheap, because it will surprise you. On the premise of ensuring quality and performance, AK2000C has reduced some functions on the basis of AK2000S , but in the professional mirrorless camera stabilizer, the cost performance is super high. Everyone can have a professional camera stabilizer, capture what you love!
Rotatable Range: Tilt: 230°(with limitation) / Roll: 306°(with limitation) / Pan: 360°(Unlimited)
Usage time: 7 h for normal working state, 12h for standby mode
Charging Time: ≥1.5h ( Support all the normal charger and quick charger which charging power ≤18W )
Materials in main body: Aluminum Alloys
Weight: 1078g/2.38 lb ( Built-in battery, not included shutter release cable, camera, lens and so forth )
Playload: 2.2Kg/4.85 lb
Water-Proof Grade: Not Water-proof
Three-axis motor lock
▪ Gimbal Stabilizer Compatibility here has 2 senses: Basic/original meaning is camera can be well balance in the gimbal stabilizer to prevent unwanted movements like camera shaky. In this dimension, ensure camera with lens size and weight is within gimbal blance standard; Advanced meaning is control camera from gimbal stabilizer like snapshot,record video, zoom , follow focus and camera parameters via cable/Wi-Fi. But different cameras have different control standard. We are working hard to make it more applicable;
▪ Unlock the motor: AK2000S has a three-axis motor lock. Before installing the camera, you can unfold each axis and lock the motor lock to assist in installing the camera. After the installation is complete, the three-axis motor lock must be unlocked and the center of gravity must be leveled, and then turn on the machine.
AK2000C Camera Model & Lens Balance Compatibility Reference:
Popular DSLR& mirrorless camera supported (Check Camera Compatibility Lists for more details, will be updated continuously) :
1.SONY：A9 series、A7 series and other DSLR camera series；A6300/A6400 and other Mirrorless camera series; Lenses:SONY FE28-70mm f/3.5-5.6 OSS、SONY E PZ16-50mmf/3.5-5.6 OSS and etc.
2.CANON：EOS R、5D Mark IV、M50、6D、600D、80D and other cameras with similar size and weight; Lenses:Canon EF 24-70mm f/2.8L II USM、Canon EF 24-105mm f/4L IS USM and etc.
3.Panasonic : GH4、GH5/GH5S、GX9、GF9 ; Lenses: OLYMPUS M.ZUIKO DIGITAL ED 12mm f/2.0、LUMIXDG Summilux 25mm f/1.4 ASPH、LUMIXG 12-32mm f/3.5-5.6 and etc.
4.Nikon：Z7、D7500; Lenses: NIKKOR 18-140mm f/3.5-5.6G ED VR and etc.
5.FUJIFILM: XT4/XT3/XT2、XH-1and etc.
AK2000C Gimbal Camera Size and Weight Balance Compatibility Reference:
If the camera is not listed above, you can check your camera based on following standard:
Max Payload: 2.2Kg/4.85 lb(well balanced);
Camera height (include the height of viewfinder)≤120mm;
The distance from tripod socket hole to the right edge of camera(camera monitor face to us) ≤95mm;
Maximum length to end of camera lens:≤170mm.
AK2000C Gimbal Camera Function Control Details with "Cable"
▪ Sony: a6300 / a6400 / a6500 / a6100 / a6600 / a7R IV / a7R III / a7 III(A7M3) / a7SII / a7RII / a7II / a9 / a7R / RX100 IV(RX100M4) / RX100 VII(RX100M7) / RX10 IV etc.
▪ Canon: M50 / EOS R / M6 mark II / G7X mark III / EOS 200D II / EOS 90D / 80D / 6D / 5D MarkIII / 6D MarkII etc.
▪ Panasonic: GH5s / GH4 / G9 etc.
▪ Nikon: Z7 / Z6 / D7500 etc.
▪ Fujifilm: X-T200 / X-T30 / X-T20 / X-T4 / X-A5 / X-T100 / X-H1 / X-T3 etc.
AK2000C Gimbal Camera Function Control Details with "Wi-Fi"
▪ Sony: a9 / a7 III(A7M3) / a7R /a7 II(A7M2) / a7S II / a7R II / a7S / a7R / a7 / RX100IV(RX100M4) / RX100 V(RX100M5) / RX100 VI(RX100M6) / a5100 / a6000 / a6500 / a6400 / a6300 / a6100 ect.
▪ Canon: M50 / EOS R /M6 mark II / EOS RP / EOS 200D II / EOS 90D / G7X mark III / EOS 80D / EOS 6D Mark II / EOS 6D / EOS 200D / EOS 5D Mark IV / EOS 70D / EOS 77D ect.
▪ Panasonic: GH4 / DC-GF9XGK / DC-GF10KGK / GH5S / DC-GX9KGK-K / DMC-GX85 / GH5 ect.
There Are Eight Extended Ports in Single Handle
▪ On the top of sliding arm of tilt axis: One 1/4 thread hole for installation ofextension support or other accessories;
▪ On the top ofmotorof tilt axis: Type-ccameracontrolport to connectwith controlcable;
In front ofquick release plate: 1/4inch thread hole,for installation ofLens holder;
▪ At the left and right side of handle: 1/4 inch thread hole to extension support othe accessories, such as monitor, Mic , versatile arm and so forth;
▪ At the bottom of the handle：1/4inch thread hole and 3/8inch thread hole to mountTripod or other accessories;
▪ At the right side of handle: USB-C port for quickcharging & update firmware(need aseparate USB adapter);
▪ Monopod（pay attention to its max payload）;
▪ Multifunctional bracket + rod +long screw;
▪ Carbon Fiber Extension Rod;
▪ Wireless microphone kit: wireless microphone ( transmitter terminal )*1、wireless microphone (receivingterminal)*1，wireless clip-on microphone *1;
▪ Versatile arm + tighten screw*1 set(the same as AK2000S);
▪ Hyperlinkremote controller;
